Musculoskeletal injuries and fractures account for 3.7% and 1% of a general practitioner’s (GP) workload in Australia, respectively.1 Because low-risk fractures rarely require orthopaedic intervention, some Western countries manage these cases within general practice.2 Limited musculoskeletal education3 and inadequate remuneration, however, are significant barriers. Medicare item numbers typically allow only a single billing for the entire fracture management, often failing to cover the time and materials required. A common example is the ‘treatment of fracture of the distal end of the radius or ulna (or both) by cast immobilisation’.4 In New Zealand (NZ), where primary care fracture management is more common than in Australia, GPs receive 150% of the Australian remuneration for similar in-hours management of fractures that require two plaster applications, adjusted for exchange rates.4,5
Because of high GP referral rates for fractures to hospital, one Queensland hospital and health service (HHS) commissioned a primary care fracture clinic (PCFC) at the Ochre Medical Centre Sippy Downs,6 which also has an urgent care clinic (UCC).7 This PCFC was subsidised by the HHS for consumables and managed 23% of the referrals to the hospital fracture clinic using upskilled GPs.6 There were seven most frequently managed fractures in the clinic (Box 1), with a 5.5% re-referral rate back to the hospital fracture clinic because of clinical complexity, fracture movement or healing impairment.6 The co-location of the PCFC with an UCC in general practice is ideal. A study compared an UCC, which was co-located with this PCFC, and managed non-life-threatening injuries including basic fractures, to an after-hours general practice and emergency department (ED). The study found that UCCs are well suited to manage non-life-threatening injuries like basic fractures because of the availability of imaging, consumables and doctors with necessary skill sets.8 The 10 years of operation of the PCFC demonstrates fractures can be managed in primary care. Further studies are being developed on the appropriate management of upper and lower limb fractures in primary care based on the report from the PCFC6 (Box 1). These studies will outline guidelines for GPs, including inclusion and exclusion criteria for fractures suitable for primary care management, ensuring appropriate case selection and safe practice.
This study describes how fractures can be managed in a PCFC, co-located with an UCC that operates seven days per week. There are several considerations that are important if this model is to be reproduced. In addition to having appropriate imaging facilities preferably onsite, it is important to ‘get set up for fracture management’, understand ‘the fracture healing process’, ‘learn initial examination and management principles’ and have an ‘appropriate referral network’. These considerations will be discussed below.
| Box 1. Seven most frequently managed fractures in the Primary Care Fracture Clinic (non-operative)6 |
| Item: |
| Distal radius ± ulnar |
| Distal fibula ± tibia |
| Phalanges |
| Patella |
| Scaphoid (and other in carpus) |
| Clavicle |
| Humerus |
| Adapted from Clinical Excellence Division, Queensland Health. Evaluation report Sunshine Coast Hospital and Health Service Primary Care Fracture Clinic. State of Queensland, Queensland Health, 2017, under a Creative Commons Attribution 3.0 Australia license. |
Aim
This article examines the fundamental principles of fracture management from the ongoing PCFC located at Ochre Medical Centre Sippy Downs, with the goal of encouraging GPs and HSS to do adopt similar practices.
Essentials for basic fracture management in general practice
Effective management of a PCFC requires proper set up for fracture care; a thorough understanding of fracture healing; proficiency in initial examination and management principles; and an established referral network.
Proper set up for fracture management
The set up for a PCFC includes ensuring access to imaging, reference materials, consumables and appropriate medical insurance. The Bettering the Evaluation and Care of Health (BEACH) study reported imaging was requested in 30.9% of musculoskeletal injuries presenting to general practice.1 This proportion might be higher in general practice-based UCCs,9 where injury presentation can be over 2.5-fold higher, with imaging referrals more than 2.3-fold more frequent.8 To ensure appropriate ordering of radiology, adherence to evidence-based guidelines, such as the Ottawa Knee and Ankle rules, is recommended.10,11 It is also important to have access to online and hard copy reference materials and consumables (Table 1).
Medical insurance companies differ in the coverage they provide ‘non-procedural’ GPs for managing fractures. Some allow ‘non-procedural’ GPs to manage ‘simple fractures and dislocations – closed reductions not requiring general anaesthesia and includes necessary non-continuous IV medications/sedation’,12 whereas other medical insurers cover ‘orthopaedics including reduction of simple fractures’ in their ‘GP Procedural’ category, which attracts a different premium.13
| Table 1. Reference materials, splinting materials and cast room accessories for the management of fractures in general practice |
| Reference materials |
Splinting materials22 |
Cast room accessories22,37 |
Hard copy:
- Practical fracture treatment18
- McRae’s orthopaedic trauma and emergency fracture management14
- Simon’s emergency orthopaedics44
Online
- Orthobullets38
- Radiopaedia39
- The Royal Children’s Hospital Melbourne40
- Diagnostic imaging pathways41
- Ottawa knee rule10
- Ottawa ankle rule11
|
Gypsona® Plaster of Paris or fibreglass casting bandage with:
- Gloves
- Scissors
- Towels
- Bucket
- Stockinette
- Natural orthopaedic padding
- Crepe bandage
Dynacast Prelude with:
- Scissors
- Towel
- Water bottle
- Crepe bandage
Splints:
- Knee immobilisers
- Lower leg walkers
- Shoulder immobilisers
- Collar and cuff supports
- Wrist immobilisers
- Wrist and thumb immobiliser
|
- Cast scissors
- Cast removal shears
- Cast spreaders
- Cast saw
- Cutting and non-cutting equipment for ring removal
- Protractor
- Ruler
- X-ray box
|
Understand the fracture healing process
For most fractures, there are four phases to bone healing (Figure 1). First, inflammation that occurs within the first week, accompanied by fracture haematoma.14 The haematoma develops rapidly into a clot, which serves as a scaffold for new fibrous tissue and bone formation, and is accompanied by vasodilation, oedema formation and inflammatory mediator release.15 Second, soft callus that occurs within weeks 2–3, where granulation tissue is replaced by fibrous connective tissue and cartilage, causing fracture ends to become sticky.14 The most amount of healing happens around the capillary buds that invade the site of the fracture.15 Third, hard callus in weeks 4–12, where bone formation begins in the soft callus where strain is lowest.14 The callus is then ossified with the deposition of calcium hydroxyapatite crystals.15 Finally, remodelling, which can take weeks to years where woven bone is replaced with lamellar bone, especially where the load is greatest.14 This prolonged period is characterised by cycles of osteoclast activity and new bone formation.15 It is this fracture healing process that guides management.
Figure 1. Clinical example of humerus fracture healing.
Reproduced from Ghiasi MS, Chen J, Vaziri A, Rodriguez EK, Nazarian A. Bone fracture healing in mechanobiological modeling: A review of principles and methods. Bone Rep 2017;6:87–100. doi: 10.1016/j.bonr.2017.03.002, with permission from Elsevier.42
Follow initial examination and management principles
At initial presentation of suspected fractures, it is important to examine the injured area, the joint above, the joint below and neurovascular status,14 as well as obtain appropriate X-rays of the affected region.16,17 Some fractures commonly present alongside other injuries; for example, calcaneal fractures are associated with contralateral calcaneal injuries and dorsolumbar fractures (5%).18 Despite radiography being the imaging standard for detecting fractures after trauma, missed diagnoses can occur with potentially significant clinical consequences.19 A systematic analysis of missed extremity fractures in emergency radiology found the overall percentage of missed fractures in the extremities in the ED was 3.7%.20 Important ways to reduce the chance of missed fractures include always getting an anteroposterior (AP) and lateral view;14 discuss and document follow-up of the injury; preparing patients that they might be called if the radiologist finds a fracture the doctor has not seen;20 and having a medical director responsible for the follow-up of results, as occurs in UCCs in NZ.21 If the injury requires immobilisation with materials like Gypsona® Plaster of Paris (BSN Medical Limited; Essity, Stockholm, Sweden), Fibreglass casting bandage or Dynacast Prelude® (Essity UK Ltd, Dunstable, Bedfordshire, UK),22 handouts for cast management should be discussed, provided to the patient and documented in the patient record. In Queensland, fracture ED factsheets exist for adults23 and children.24 Fractures should be reviewed at regular intervals to ensure adequate position and healing.
The first review of a fracture usually occurs at 7–14 days after the initial injury before soft callus starts to become hard callus in the fracture healing process.14 During review, the condition of the injury and position of the fracture can be checked by X-ray, with referral to an orthopaedic surgeon if either is unsatisfactory. Casting material can be changed from Gypsona® Plaster of Paris to fibreglass.
Further review can occur at three or more weeks for upper extremity fractures and four or more weeks for lower extremity fractures depending on the injury, to assess healing and restarting movement.17 Important to fracture healing is strain, which if insufficient can cause removal of callus and delayed union, but if excessive and too early, it can affect healing by fracture of the callus.15 When assessing the stiffness of a fracture, one study of ‘fracture healing assessment comparing stiffness measurements using radiographs’ concluded ‘criteria for determining healing based on radiographic appearance is debatable’.25 Although there is no gold standard, radiographic modalities, clinical assessment (no localised tenderness or heat, no abnormal movement or crepitus), mechanical assessment (no pain on normal loading) and patient-reported measures are used to determine fracture healing.14,26 An important question in fracture healing is: when is fracture strength at a level to allow an athlete return to sport after a fracture? A scoping review and survey of ‘return to sport after forearm fractures in children’, which are the most common fractures in children, found few published recommendations.27 Using a multidisciplined approach involving medical experts and other stakeholders with the capacity to integrate technology, rehabilitation and performance can help guide and monitor obstacles to returning to sport for athletes.28 At further review, if the fracture site is still tender, it might be appropriate to continue to immobilise for another 7–10 days before further review.
Develop a referral network
Care coordination is part of the role of specialist GPs where individualised treatment plans and care coordination is provided along with connection to other healthcare providers.29 A PCFC involves coordination with orthopaedic and allied health practitioners, preferably written, otherwise with oral conversations documented. It also involves providing information resources. These referral networks can include sharing of photographs of imaging. Legal and ethical considerations for sharing X-rays using medical photography include documented consent (preferably written, otherwise oral), data protection (password-protected mobiles with back-up systems disabled and encryption), accuracy of capture30 and de-identification.31
Orthopaedic surgeons need to be involved in the acute or semi-acute management of certain fractures. This includes cases where the fractures are open, displaced, neurovascularly compromised or when significant pathology is suspected. Open fractures occur when there is a fractured bone and skin break in the same limb segment.14 This increases risk for infection and non-union.32 It should be assumed that skin breaks have direct communication with the fracture, even if the open wound is not directly over the fracture.14 Initial treatment includes intravenous antibiotics, anti-tetanus toxoid if required, removal of gross contamination and covering with a simple sterile-soaked dressing and splinting/casting14 and referral for operative debridement.32 Administration of antibiotics within three hours of injury has been found to have an infection rate of 4.7%, whereas those administered after three hours had a higher infection rate of 7.4%.32 An example of a fracture with significant pathology is a trans-scaphoid perilunate dislocation with capitate lunate disruption, dorsal displacement of the capitate on the lunate, fracture through the waist of the scaphoid with a maintained radial lunate articulation (Figure 2).
Certain fracture types require semi-acute orthopaedic involvement, typically managed through a fracture clinic because of a high complication rate. These include fractures of the proximal pole of scaphoid, talus, calcaneus14 and Salter Harris III to V fractures. Salter Harris III and IV fractures generally require open reduction and internal fixation, and Salter Harris V fractures have a potential for growth arrest; therefore, Salter Harris III and V fractures should involve an orthopaedic surgeon for management.33 If a fracture is not healed within 10 weeks, the PCFC should refer patients for orthopaedic opinion. In addition to support from an orthopaedic service, it is important to advise patients with fractures about rehabilitation and time frames for rehabilitation.
Ideal management after traumatic injury such as a fracture should typically involve rehabilitation.34,35 In Australia, the Medicare Benefits Scheme allows GPs to coordinate ‘Team Care Arrangements’ (TCA) involving allied health practitioners such as physiotherapists, podiatrists, psychologists and exercise physiologists following traumatic injury; however, to qualify, the medical condition must be present or expected to persist for at least six months.36 Unfortunately, for many Australians, allied health practitioner-assisted rehabilitation is cost prohibitive. An affordable alternative is to provide information resources to patients.
Figure 2. Trans-scaphoid perilunate fracture dislocation. (A) Frontal X-ray. (B) Lateral X-ray.
Reproduced from Gaillard F. Trans-scaphoid perilunate fracture dislocation (rID: 18058). Radiopaedia.org, 2012. Available at https://radiopaedia.org/cases/trans-scaphoid-perilunate-fracture-dislocation, with permission from Radiopaedia.org.43
R, right.
Conclusion
GPs can effectively manage low-risk fractures within primary care if they are appropriately set up, have a clear understanding of fracture healing, are trained in initial examination and management principles, and have a referral network. Set-up includes establishing protocols, securing appropriate medical insurance and ensuring access to reference materials and necessary consumables. Referral networks should include orthopaedic surgeons, allied health professionals such as physiotherapists, along with providing suitable patient education materials.
Key points
- Low-risk fractures are being managed in Australia and internationally by doctors trained in musculoskeletal medicine.
- Getting set up for a PCFC involves ensuring access to imaging, reference materials, consumables and the right medical insurance.
- Understanding basic fracture healing informs management of the fracture episode.
- Learning initial examination and management principles allows low-risk fractures to be managed in general practice and high-risk fractures to be managed by the orthopaedic surgeon either acutely or semi-acutely.
- Having a referral network that includes orthopaedic surgeons, allied health practitioners like physiotherapists and appropriate handouts allows specialist GPs to thrive in their role as care coordinators who can individualise treatment for patients.
